Hardware · System Integration
A versatile industrial protocol converter that seamlessly bridges communication between legacy and modern industrial systems. Eliminate integration barriers without replacing existing equipment — simply plug in, configure, and connect.
.png)
Transparent, bidirectional protocol conversion with zero data loss and minimal latency.
Simultaneously converts between Modbus RTU/TCP, PROFIBUS DP/PA, BACnet MS/TP & IP, IEC 60870-5-101/104, DNP3, CANopen, M-Bus, and more.
Sub-5ms conversion latency ensures real-time responsiveness is preserved across protocol boundaries. Transparent conversion with no data alteration.
Configurable register and data point mapping with support for scaling, engineering unit conversion, bit manipulation, and custom data type transformations.
Fully configure all conversion parameters through an intuitive web interface — no specialist software or programming expertise required.
Surge and transient protection on all ports. Wide operating temperature range. Built to withstand the electrical noise and harsh conditions of industrial environments.
Built-in packet sniffer, communication statistics, and live register viewer for fast commissioning and troubleshooting without additional test equipment.
The Prizma Protocol Converter is the integration glue that makes heterogeneous industrial networks work. Whether you need to connect a 30-year-old PROFIBUS device to a modern SCADA system, or expose a Modbus meter to a BACnet building management system — our converter handles it transparently.
No programming. No custom drivers. No expensive system redesign. Simply configure the source and destination protocols through the web interface, map your data points, and the converter handles all translation in real time — automatically and continuously.
.png)
| Protocol | Mode |
|---|---|
| Modbus RTU | Master / Slave |
| PROFIBUS DP | Master / Slave |
| PROFIBUS PA | Master / Slave |
| DNP3 Serial | Master / Outstation |
| IEC 60870-5-101 | Master / Slave |
| BACnet MS/TP | Master / Slave |
| M-Bus | Master |
| CANopen | Master / Slave |
| Protocol / Spec | Detail |
|---|---|
| Modbus TCP | Client / Server |
| IEC 60870-5-104 | Master / Slave |
| DNP3 TCP/UDP | Master / Outstation |
| BACnet/IP | Client / Server |
| OPC-UA | Server |
| Ethernet Ports | 2× 10/100 Mbps |
| Serial Ports | 3× RS-485, 1× RS-232 |
| Operating Temp | -40°C to +75°C |
Connect older PROFIBUS or serial field devices to modern Ethernet-based SCADA without replacement.
Bridge Modbus energy meters and HVAC controllers into BACnet building management systems.
Convert IEC 60870-5-101 serial to IEC 60870-5-104 Ethernet for modern EMS/SCADA integration.
Aggregate data from M-Bus meters and Modbus devices into a single unified energy management platform.
Tell us about your integration challenge and our engineering team will confirm compatibility within 24 hours.
